ABT 2-Beam IR Barrier (20–100m)
Detection distance: 20m / 30m / 40m / 60m / 80m / 100m
| Model |
Detection distance |
| ABT-20 |
20m |
| ABT-30 |
30m |
| ABT-40 |
40m |
| ABT-60 |
60m |
| ABT-80 |
80m |
| ABT-100 |
100m |
Infrared Beams: 2 beams (Through-beam type) / Detection Method: 2-beam interruption detection / Response Time: 50–700 msec / Alarm Output: NO/NC selectable / Power Supply / Voltage: DC 13.8–24 V ; AC 11–18 V / Current Consumption: Max. 40 mA / Operating Temperature Range: –25 °C to +55 °C / Optical Axis Adjustment (Horizontal): 180° (±90°) / Optical Axis Adjustment (Vertical): 20° (±10°) / Housing Material: Aluminum, PC engineering plastic
Illustration for reference. High-res photos & datasheet sent on RFQ.
